Client: A logistics company in Hubei Province
Project time: 2014
Project profile
All of the design schemes and installation projects of the food logistics cold storage warehouse are completed by Haocool and the project includes 4 cold storage warehouses and 6 freezers.
| Cold storage warehouse capacity | 25000m3 | Storage capacity | 8000 tons |
| Storage cargo | Foods | Cargo handling method | Manual |
| Height of cold storage warehouse | 8m | Cargo storage method | Cargo shelf |
| Construction time | March 2014 | Construction period | 80 days |
| Cold storage warehouse classification | Logistics cold storage warehouse | Building structure | Steel |
Haocool developed the following design scheme according to the project
| Design temperature | Cold storage warehouses is 0-5℃, freezer is -15~-25℃ |
| Refrigerating unit | Adapting the famous compressor brand Bitzer parallel units |
| Power supply | 380V or 415V, 3 phase, 50-60Hz |
| Condensation method | Evaporative condenser |
| Evaporation method | Aluminum calandria+air-cooler |
| Defrosting method | Electric heating defrosting |
| Liquid feed method | Barrel pump liquid feed |
| Freezing medium | Environmentally friendly freezing medium |
| Electronic control method | PLC long-distance intelligent control, real-time inspect: cold storage warehouse temperature, draught fan operating state, defrosting state |
| Cold storage warehouse thermal insulation | Directly sprayed polyurethane |
| Cold storage warehouse door | Polyurethane single leaf sliding door |
This design scheme was praised by the clients, and the project was completed on December 30, 2014.
